Baterei Kendaraan Listrik 60v 40ah 50ah 65ah Baterei

2023-08-24 08:06

Spesifikasi

Parameter Fungsi
Nomin Battery Energy	3900wh
Nomin Kapasitas	65Ah
Nomin Tegangan	60V
Resistensi internal	≤22mΩ
Urip Siklus	> 6000
Wulan Sasi Dibuwang	<3%
Ngisi Data
Tegangan Ngisi Normal DC	54.75±1Vdc
Mode Ngisi daya	0.2C nganti 54.75V, banjur 54.75V, ngisi saiki nganti 0.02C (CC/CV)
Dianjurake Charger Saiki	≤50A
Diijini Max. Ngisi Arus	50 Adc
Tegangan Tegangan Timbang	54.75±1Vdc
Data Discharge
Saiki Ngirim Terus-terusan	50A
Diijini Max. discharge saiki	100A (pilihan: 100Adc)
Rang saka tegangan discharge DC	37.5V-54.75Vdc
Kondisi Kerja
Suhu Pangisi daya	0 ℃ nganti 45 ℃ (32 ℉ nganti 113 ℉) @60 ± 25% Kelembapan Relatif
Ngeculake Suhu	-20 ℃ nganti 60 ℃ (-4 ℉ nganti 140 ℉) @60 ± 25% Kelembapan Relatif
Suhu Panyimpen	0 ℃ nganti 40 ℃ (32 ℉ nganti 104 ℉) @60 ± 25% Kelembapan Relatif
Tingkat Proteksi Enclosure	IP67

Fitur

1.Rechargeable battery
2.Use of Iron(Fe) as a cathode material
3.Higher discharge current
4.Do not explode under extreme conditions and weight less

Kaluwihan

1.Extremely high rate capability
2.Safe lithium battery
3.Good storage characteristics
4.Good high temp performance
5.Long cycle life to 2000 times
6.High capacity & light weight
7.Environmentally friendly
8.No memory effect

Kita bisa nyedhiyani sampeyan karo layanan selaras

Customized 7.4V-12V-24V-36V-48V-52V-60V-72V...LITHIUM BATTERY PACK

Kapasitas lan ukuran bisa ngatur miturut panyuwunan sampeyan:

1. Ukuran batere khusus lan bahan cangkang

2. Ngisi daya BMS khusus lan ngeculake saiki

3. Plug and socket sing disesuaikan, kabel konektor

AIN Aplikasi Utama Paket Baterai Lithium
Aplikasi propelling listrik	batere mesin wiwitan; Mobil Cepet Alon; robot intelektual; sepeda listrik / motor / skuter; troli golf / kreta / mobil wisata; alat listrik.
Panyimpenan energi	sistem tenaga surya lan angin; kothak kutha / mati; komunitas lan kulawarga, RV Caravan, kapal pesiar Laut.
Sistem serep lan UPS	Telecommute base, CATV-system, computer server center, medical instrument, military equipment.
Aplikasi liyane	keamanan lan elektronik; POS seluler, lampu pertambangan / obor / Lampu LED / lampu darurat.

Perusahaan Kita

WHY CHOOSE US?
1.Our company has 13 years experience in battery R&D,producing and the overseas marketing.
2.Flexible customizing and Manufacturing
3.6,000,000Ah monthly production capacity
4.Each process for making battery were under strict management and control,all of the battery were under full inspection before delivery.
5.With professional R&D team, experienced workers and advanced requirements, we are determined to provide you high-quality battery.

6.Support prompt shipment and sample quality products,track the cargo in time after delivery.More than one year Guarantee,we will give instruction for how to use our products.



FAQ

P: Apa garansi sampeyan?
A: We guarantee the quality before the item is shipped. The warranty will be offered based on different type of battery. Any damages caused by improper use are not covered by our warranty.

Q: What is delivery time if we place an order?
A: It depends order quantities. Usually, we can deliver goods within 3 -5 working days for small orders, for more QTY. order, let's confirm when you place offical order.

Q: Are your factory or trading company?
A: We are professional lithium-ion rechargeable batteries manufacturer with our own factory and brand. We provide all kinds of OEM/ODM services for clients around globe.
